Knife steel selection in a working knife shop

Knife steel

CPM S45VN knife steel

A premium powder-metallurgy stainless steel from Crucible, built on S35VN with more chromium and nitrogen for stronger edge retention and corrosion resistance at only a small toughness cost.

Also known as

  • S45VN

At a glance

How CPM S45VN behaves

The four meters are relative to the rest of the database. Composition is the published nominal analysis, not a mill certificate for your bar.

Working properties

Toughness
4 / 5
Edge retention
5 / 5
Corrosion resistance
4 / 5
Ease of grinding
3 / 5
Composition
  • Carbon (C)1.48%
  • Chromium (Cr)16.00%
  • Vanadium (V)3.00%
  • Molybdenum (Mo)2.00%
  • Niobium (Nb)0.50%
  • Nitrogen (N)0.15%
Best uses

A top pick for high-end EDC folders and outdoor knives where corrosion resistance and edge retention both matter. Larrin Thomas rates its corrosion resistance 8 of 10, and in Crucible's 72-hour 1% saltwater spray chart it showed about 40 rust spots, so it is fine in wet use with care (wipe it dry afterward) but it is not a saltwater steel: look at LC200N or Vanax for constant salt exposure. Browse more entries in the Knife Steel Database, and see the Heat Treating Guide for the full stage-by-stage process.

Sources
  • Crucible Industries CPM S45VN datasheet
  • Larrin Thomas, Crucible S45VN Steel: Everything You Need to Know, Knife Steel Nerds.
Satin-finished flat stock bar on one black felt pad and a cold knife blank with pin holes on another, in a small shop.

At the bench

What each property means for this steel

Open the property you are worried about. Every note is written for the blade in your hand, not for a spec sheet.

Toughness
Only slightly less tough than S35VN despite the higher carbide load, and still an improvement over S30V once hardness is accounted for.
Edge retention
Rated around 143% CATRA edge retention versus 440C, matching S30V and beating S35VN, among the better edge-holding stainless steels in this class.
Corrosion resistance
Crucible's data sheet describes S45VN as improved over S35VN in corrosion resistance, thanks to 16% chromium and a nitrogen addition. Larrin Thomas rates it 8 of 10 against 7.5 for S35VN and 9.5 for MagnaCut. In Crucible's 72-hour 1% saltwater spray chart it showed about 40 rust spots (S35VN about 90, MagnaCut none).
Grinding and machinability
Grinds similarly to S35VN, moderate for a powder-metallurgy steel; expect faster belt wear than simple carbon or basic stainless steels.
Quench and temper decide whether CPM S45VN gives you the numbers above.
Cold knife blade with a fine lengthwise scratch finish, tang clamped to a wood board, an abrasive block on the bevel and a grit strip beside it.

The full reference

More on CPM S45VN

CPM S45VN is Crucible’s next step up from S35VN, rebalancing the chemistry with more carbon, more chromium, and a nitrogen addition to push edge retention and corrosion resistance higher while giving up only a little toughness. The result is one of the best all-around premium stainless steels available, and a common choice for high-end EDC and outdoor knives.

Open everyday folding knife with a satin drop-point blade and green textured handle on a charcoal pad beside coiled cord.

Head to head

Compare steel data for CPM S45VN

Every matchup CPM S45VN appears in, dimension by dimension.

Keep reading

Guides that use this steel
